Analog Dial Gauges / Thickness Measuring Devices

Precision Dial Gauge

Shockproof | According to DIN 878-A

680S

Standard type

681S

Lever fine adjustment

6080

economic type Ø 60mm

Small Precision Dial Gauge

Shockproof | According to DIN 878-A

A-684S

3mm Measuring range

B-684S

5mm Measuring range

Precision Dial Gauge

Shockproof

683-30S

30mm Measuring range

683-50S

50mm Measuring range

Hand Tally Counter

972

Display-digits: 4
Capacity: 9999
Height of figures: 4,5mm
Ø 47mm

Thickness Measuring Device

670M

Thickness Measuring Device

675

Thickness Measuring Device

676

Thickness Measuring Device

1 rotation of lever = 1 mm measuring distance

671

without relieving unit

Thickness Measuring Device

1 rotation of lever = 1 mm measuring distance

672

with relieving unit

Thickness Measuring Device

1 rotation of lever = 1 mm measuring distance

673

with relieving unit
Scale value: 0,01mm
Measuring range: 10,0mm
Depth of frame: 100,0mm

674

with relieving unit
Scale value: 0,01mm
Measuring range: 10,0mm
Depth of frame: 200,0mm

Measuring inserts for thickness measuring devices

Please state when ordering thickness measuring devices

a

Ø 30mm for rubber planket, rubber plates, felts, soft materials

b

Ø 20mm for rubber planket, rubber plates, felts, soft materials

Measuring inserts for thickness measuring devices

Please state when ordering thickness measuring devices

c

Ø 10mm for soft leather, cardboard, paper, films

Measuring inserts for thickness measuring devices

Please state when ordering thickness measuring devices

d

Ø 10mm for hard leather, plywood, fibre boards

Measuring inserts for thickness measuring devices

Please state when ordering thickness measuring devices

e

Ø 5mm for sheet steel etc.
